Pneumatic Peanut Butter Filling Machine

Technical Specification
Machine model: YSGG1000
Voltage:220V 50Hz /110V 60Hz
Hopper capacity: 30L
Power:10W
Filling error ≤0.5%
Filling range 100-1000ml
Filling speed about 10-25 bottles/min
Air pressure: 1000W air compressor ; 0.7mpa air pressure
Filling nozzle diameter:10mm(If need 4mm/6mm/8mm /12mm /14mm ,it can be customized)
Machine size:90x30x30cm
Package:105*40*41cm ; 30KG
hopper : 48*48*57cm,9KG
Total Gross Weight: 60kg

分类: .

Product Description

Product Description

Technical Specification
Machine model: YSGG1000
Voltage:220V 50Hz /110V 60Hz
Hopper capacity: 30L
Power:10W
Filling error ≤0.5%
Filling range 100-1000ml
Filling speed about 10-25 bottles/min
Air pressure: 1000W air compressor ; 0.7mpa air pressure
Filling nozzle diameter:10mm(If need 4mm/6mm/8mm /12mm /14mm ,it can be customized)
Machine size:90x30x30cm
Package:105*40*41cm ; 30KG
hopper : 48*48*57cm,9KG
Total Gross Weight: 60kg
Driven by a cylinder and piston made from materials with one-way valves control the flow of materials; Magnetic reed switch control cylinder itinerary can be regulated filling volume; Rational design of the aircraft, model compact, easy to operate; Advanced and high quality AirTAC pneumatic components; Some contact materials are 316 L stainless steel materials, in line with the GMP requirements; Filling volume and speed of filling can be arbitrary regulation, filling high accuracy; Widely used by industries in the Food & Beverage, Cosmetics, Personal Care, Agricultural, Pharmaceutical, and Chemical fields; An ideal device for paste and high viscosity liquid filling.
President Notice 1.We offer 12month warranty service.. 2.We have the machine IN STOCK, we send out within 1-2 days after you place the order. 3 We use DHL,FedEx ,UPS service , you can get the machine within 4 -6 days. 4.We are the manufacture factory. we can supply all parts what you need . NOTE Pls leave us what do you want to fill ? And what is your filling volume? And if your particle is bigger than 5mm,pls contact with us, we will change the rotary valve to bigger ones, and will change the filling head and filling nozzle to bigger ones. And if you fill the corrosive stuff we will ship you the teflon seal ring part, pls contact with me . please tell us your filling range:Such as 10-100ml.20-200ml,50-500ml,100-1000ml.260- 2600ml.350-3500ml.500-5000ml. Different filling range have different price.
